    Summit 47″ x 55″ Horizontal Boring Mill, HBM110-H

    Inventory # 8101

    Model: HBM110-H

    Description:

    Summit Horizontal Boring Mills offer the perfect combination of affordability, efficiency, and precision performance for metal machining. This horizontal milling machine is a versatile, heavy-duty and user friendly machine tool that provides years of profitable, trouble-free operation. Summit Horizontal Boring Mills utilize the latest technologies to meet the ever increasing demand for greater productivity

    Specifications:

    Spindle:

    Diameter of Spindle: 4.3″

    Taper of Spindle: # 50 NMT

    Spindle Speed: 20 – 1,500 RPM (Variable)

    Travels:

    Vertical Travel (Y-Axis): 55.1″

    Cross Travel (X-Axis): 70.8″

    Saddle Travel (W-Axis): 55.1″

    Spindle Travel (Z-Axis): 21.6″

    Feed Range (X, Y, & W): .118 – 37.4 IPM

    Rapid Traverse (X, Y, & W): .118 – 15.75 IPM

    Table:

    Size of Table: 47.2″ x 55.1″

    Max. Weight of Workpiece: 11,000 lbs.

    Table Height from Floor: 49″

    Table T-Slot Width: .875″

    Rotation: Manual

    Increment: 1°

    Motor: 20 HP / 220v, 440v / 3ph

    Standard Features:

    Precision hardened and ground bedways

    Fully automatic lubrication system

    Precision ground ballscrews with preloaded double nuts on X, W, and Z-Axis

    State of the art electrics with PLC control

    Rapid traverse in all feed directions

    Full steel telescoping way covers on X and W-Axis

    Air power drawbar

    Built-in rotary table – 360° – 6,600 lbs. capacity

    Three/Four axis electronic DRO included (incorporated into the pendant display)

    Hydraulic clamping (X, Y, and W-Axis)

    Mechanical Specifications:

    Dimensions: 208″ x 161″ x 143″ H

    Weight: approx. 32,500 lbs.

    Contact us for special pricing and availability

    FOB Factory

    Additional information

    Weight 32800 lbs
