Description
Clausing Kalamazoo 10″ Wet Cutting Horizontal Band Saw, KC1016VS
Inventory # 4975
Model: KC1016VS
Specifications:
Cutting Capacity:
@ 90°:
Round: 10″
Rectangular: 9″ x 14 1/2″
@ 45°:
Round: 9″
Rectangular: 9″ x 9″
Band Wheel Diameter: 15″ Flanged, Cast Iron
Blade: 1″ x .035″ x 11′
Bed Height: 25″
Blade Speeds: 50 – 295 FPM
Motor: 2 HP / 230v, 460v / 3ph OR 1.5 HP / 110v, 220v / 1ph (Please Specify Desired Motor at Time of Order)
Standard Features:
1.5 HP – 2 HP drive motors with magnetic starter and overload protection
Magnetic starter with overload protection
Infinitely variable speed drive
Totally enclosed transmission
Heavy-duty hydraulic cylinder with precision ground hinge support
Pan shaped base with built-in coolant and hydraulic system
Cast iron bed
Cast iron quick acting 0° – 45° vise with manual leadscrew clamping system
Two additional bearing to support blade from the top
Recirculating coolant system with applicaton through both guides
Blade brush
Valve controlled hydraulic cylinder controls feed and can be adjusted for different types and sizes of material
Adjustable stock stop
Simplified control switches mounted on saw head
Anti-slip hand wheel
Easy blade change with front access at waist level
1″ wide blade
Tools
Operation and parts manual
Two year limited warranty
Mechanical Specifications:
Shipping Dimensions: 67″ x 31″ x 48″ H
Shipping Weight: approx. 950 lbs.
Contact us for special pricing and availability
FOB Factory
