Description
Adira 10′ x 90 Ton CNC Press Brake, QH-9030
Inventory # 9900-C
Model: QH-9030 “1985”
S/N: 1622/3544
Specifications:
Tonnage: 90 Tons
Bed: 122″ (10′)
Distance Between Housings: 100″
Stroke Adjustment: 4″
Stroke Length: 4″, Max.
Throat Depth: 17.72″
Distance Over Bed: 118″
Max. Open Height without Die Adapters: 12.20″
Max. Open Height with European Die Adapters: 8.66″
Distance Below Floor: 4″
Ram Operation Speeds, Approach:
Fast: 2 IPS
Standard: 1 IPS
Bending: .40 IPS
Return: 1.57 IPS
Motor: 8.8 HP
Equipment Included:
4-Way Bottom Die
Segmented Top Goose-Neck Knife
Bending Depth Control
Tonnage Gauge
Full Length Foot Treadle
Mechanical Specifications:
Dimensions: 126″ x 64″ x 90″ H
Weight: approx. 11,700 lbs.
FOB Our Baltimore, MD Warehouse
