Acer 17″ x 60″ Precision Inverter Engine E-Lathe with Newall 2-Axis DRO, 1760G – New, In Stock, & Ready to Ship!
Inventory # 10166
Model: 1760G
S/N: N24100303
Specifications:
Swing Over Bed: 17″
Swing Over Gap: 26″
Swing Over Cross Slide: 9 5/8″
Distance Between Centers: 60″
Spindle Nose: D1-6
Spindle Bore Diameter: 2 1/4″
Center Height: 8 1/2″
Spindle Speeds: 42 – 2,000 RPM (3 Ranges)
Cross Slide Travel: 8 4/5″
Compound Rest Travel: 7″
Max. Size Cutting Tool: 1″ x 1″
Tailstock Travel: 6″
Taper of Tailstock: MT #4
Bed: 96.1″ L x 11 7/8″ W
Width of Gap: 8 3/4″ W
Threading & Feeding:
System: Inch/Metric
Metric Pitch Threads: 0.5 – 7 mm/Pitch (22 Kinds)
Inch Pitch Threads: 4 – 56 TPI (36 Kinds)
Module Pitch Threads: 0.5 – 3.5 MP (12 Kinds)
Diametral Pitch Threads: 8 – 56 DP (21 Kinds)
Range of Longitudinal Feeds: 0.002″ – 0.025″ /Rev.
Range of Cross Feeds: 0.001″ – 0.014″ /Rev.
Motor: 7.5 HP Inverter / 220v / 3ph
Standard Features:
Chuck Guard with Safety Switch
Hardened and Ground Gears, Shafts, and Meehanite Casting Bed Way
Automatic Longitudinal Multiple Feed Stop
Thread Chasing Deal
Gap Bed
Equipment Included:
Newall 2-Axis Digital Read-Out System
10″ D1-6 3-Jaw Chuck
4-Way Tool Post
Steady Rest
Built-In Coolant System
Full-Length Rear Splash Guard
Toolbox & Tools
Owner’s Manual
Mechanical Specifications:
Shipping Dimensions: 107″ x 41″ x 68″ H
Shipping Weight: approx. 4,250 lbs.
FOB Our Baltimore, MD Warehouse
